Free NTS oscillators and stuff. Now for NTS-1 mk II as well.
RoaR is a very simple oscillator that randomly generates digital sounds and sequences, with a simple turn of a knob.
Each sound can be a simple patch or a rhythmic (16 step) sequence.
You can play simple, tuned and playable sounds, or go wild with glichy, complex and total random sounds.
Rhythmic sequences can also by synced to the ARP or SEQ, or external equipment.
- Download:
- NTS1 original: roar.ntkdigunit
- NTS1 mk II: roar.nts1mkiiunit
- Detailed (very simple) instructions: RoaR Oscillator instructions
- Introduction video: https://youtu.be/vCKhyWSqCxs
J6 is a chord player oscillator and sequencer.
This oscillator is inspired by the Roland J-6 synthesizer, so you can check it out to understand the concept behind this oscillator.
Each note plays a different chord, and there are 100 different chord sets. These are the same as the Roland J-6 chord sets, that can be found at: https://static.roland.com/manuals/J-6_manual_v102/eng/28645807.html
It also includes:
- Mixable waveforms: saw, pulse, pulse suboscillator (with PWM for the pulse waves)
- 100 playing patterns (rhythmic, arpeggios and mixed)
- Transpose in semitones up to + or – 4 octaves
- 16-step sequencer with variable step length, for a max of 16 bars of chord playing
- Download:
- NTS-1 original: j6_v201.ntkdigunit
- NTS-1 mk II: j6.nts1mkiiunit
- Detailed instructions: J6 Oscillator instructions
- Introduction and Demo video: https://youtu.be/3PVx-NqOhfs
The Volca Bass oscillator copies the “architecture” of the oscillator section of the Volca Bass.
It includes 3 oscillators, each with on/off, saw/square waveform, and pitch control up to +/-1 octave.
Includes also a slide function, octave selection (even with the ribbon), and a step sequencer, with 16 steps for notes or rest, and slide selection per step.
It features 3 memory slots for sequences, and a 4th group slot, that plays all the other 3 at the same time, each to its oscillator, paraphonically.
- Download:
- NTS-1 original: a_free_osc_vbass.ntkdigunit
- NTS-1 mk II: vbass.nts1mkiiunit
- Detailed instructions: Volca Bass Oscillator instructions
- Introduction and Demo video: https://youtu.be/wE8cbGawHDo
ROAT is an 8-bit experimental oscillator inspired by the Soma "Rumble of Ancient Times" synthesizer.
It includes 4 oscillators that can be triggered independently, by pressing 4 different zones of the keyboard, or recording a step sequence.
Combining oscillator activation with the different settings per oscillator (pitch, shape, LFO) and different combination algorithms, and adding randomization and chaos, gives you a wide range of sonic possibilities, from melodic to digital noise.
Settings per oscillator:
- Pitch
- 16 different waveshapes
- LFO (for pitch or amplitude) with 8 different shapes
- 16-step rhythmic sequence, syncable with external devices
Additional features:
- 3 oscillator combination diagrams with 7 different summing algorithms per node (including FM)
- 2 randomization algorithms
- External audio processing (NTS-1 mk II only)
- Chromatic play
- Download:
- NTS-1 original: roat201.ntkdigunit
- NTS-1 mk II: roat201.nts1mkiiunit
- Detailed instructions and reference sheet: ROAT Oscillator instructions
- Introduction video: https://youtu.be/3PVx-NqOhfs
- Full instructions video: https://youtu.be/4h0m3JB5GIc
- Version 2 updates video: https://youtu.be/1ZQDBElc6ZU
Proba-B is a probability sequencer based oscillator.
Use the built-in arpeggiator or record a step sequence, from 1 to 64 steps (default is 8 steps). Then assign probability values to each step, for step mute, transpose and shape change. The oscillator waveshape itself is a triangle waveform, with wave folding (shape parameter) and frequency modulation (alt parameter).
Works great with delay effects.
Extra features include:
- microtuning
- time division
- transpose, with auto minor to major scale converter.
- Download:
- NTS-1 original: proba-b_v210.ntkdigunit
- NTS-1 mk II: proba-b.nts1mkiiunit
- Quick reference sheet: Proba-b.2.10.Reference.Sheet.pdf
- Detailed instructions: Proba-B Oscillator instructions
- Introduction and Demo video: https://youtu.be/CADbPm17Uhw
