What is Storylang?

Storylang is a language that can be used for storyboarding user experiences. It brings precision and clarity to the collaborative process for people involved in UX design and frontend development.

Storylang is JSON-compatible.

Long-term goal: Storylang must evolve into a written script notation framework that can help imagine, annotate and communicate.

Inspiration to create this was drawn from music notations.

Above: Hand-written musical notation by J. S. Bach (1685–1750).

Storylang.json Documentation

Overview

Storylang.json is a structured configuration file used in the ember-tribe ecosystem to define the frontend implementation of your application. It works in conjunction with your simplified-types.json (which defines your data models) and navigator.json (which defines user flows and navigation) to create a complete frontend specification.

Purpose

The storylang.json file serves as a blueprint for frontend developers to understand:

• What routes, components and services are required
• How data flows through the application

File Structure

The storylang.json file contains four main sections:

{
  "implementation_approach": "...",
  "components": [...],
  "routes": [...],
  "services": [...]
}

Section Definitions

1. Implementation Approach

Purpose: Provides a high-level technical overview of how the frontend interface would work.

Format:

{
	"implementation_approach": "Two-paragraph description explaining technical approach and key functionality."
}

2. Components

Purpose: Defines reusable UI components that will be built for the application.

Format:

{
	"components": [
		{
			"name": "component-name",
			"type": "component-type",
			"tracked_vars": [{ "variable_name": "data_type" }],
			"inherited_args": [{ "arg_name": "type" }],
			"actions": ["action1", "action2"],
			"helpers": ["helper1", "helper2"],
			"modifiers": ["modifier1"],
			"services": ["service1", "service2"]
		}
	]
}

Component Properties:

• name: Kebab-case name of the component
• type: Type from the built-in components list
• tracked_vars: State variables tracked within the component
• inherited_args: Arguments passed from parent components
• actions: User interactions the component handles
• helpers: Template helpers used within the component
• modifiers: DOM modifiers applied to elements
• services: Ember services injected into the component

Built-in Component Types:

• Layout: table, figure, accordion, card, list-group, navbar, nav, tab, breadcrumb
• Interactive: button, button-group, dropdown, modal, collapse, offcanvas, pagination, popover, tooltip, swiper-carousel, videojs-player, howlerjs-player, input-field, input-group, textarea, checkbox, radio, range, select, multi-select, date, file-uploader, alert, badge, toast, placeholder, progress, spinner, scrollspy

Example:

{
	"components": [
		{
			"name": "file-summary-card",
			"type": "card",
			"tracked_vars": [{ "isSelected": "bool" }, { "isExpanded": "bool" }],
			"inherited_args": [
				{ "file": "var" },
				{ "onEdit": "fn" },
				{ "onDelete": "fn" }
			],
			"actions": ["toggleSelection", "expandDetails", "editFile", "deleteFile"],
			"helpers": ["formatDate", "truncateText"],
			"modifiers": ["tooltip"],
			"services": ["store", "router"]
		}
	]
}

3. Routes

Purpose: Defines the application's routes and their requirements.

Format:

{
	"routes": [
		{
			"name": "route-name",
			"tracked_vars": [{ "variable_name": "data_type" }],
			"get_vars": [{ "param_name": "data_type" }],
			"actions": ["action1", "action2"],
			"helpers": ["helper1"],
			"services": ["service1"],
			"components": ["component1", "component2"],
			"models": ["model1", "model2"]
		}
	]
}

Route Properties:

• name: The route name (matches Ember router)
• tracked_vars: Route-level state variables
• get_vars: URL query parameters and their types
• actions: Route-level actions
• helpers: Template helpers used in route templates
• services: Services used by the route
• components: Components rendered in this route
• models: Data models loaded by this route

Example:

{
	"routes": [
		{
			"name": "files",
			"tracked_vars": [
				{ "selectedFileType": "string" },
				{ "sortOrder": "string" }
			],
			"get_vars": [
				{ "page": "int" },
				{ "search": "string" },
				{ "filter": "string" }
			],
			"actions": ["filterFiles", "sortFiles", "searchFiles"],
			"helpers": ["pluralize", "formatDate"],
			"services": ["store", "router"],
			"components": ["file-list", "file-filter", "search-box", "pagination"],
			"models": ["json_file"]
		}
	]
}

4. Services

Purpose: Defines custom Ember services needed by the application.

Format:

{
	"services": [
		{
			"name": "service-name",
			"tracked_vars": [{ "variable_name": "data_type" }],
			"actions": ["action1", "action2"],
			"helpers": ["helper1"],
			"services": ["dependency1", "dependency2"]
		}
	]
}

Service Properties:

• name: Service name
• tracked_vars: Service-level tracked properties
• actions: Methods provided by the service
• helpers: Utility functions
• services: Other services this service depends on

Built-in Services:

• store: Ember Data store for CRUD operations
• router: Ember router service for navigation

Third-party npm packages pre-installed:

• bootstrap: Bootstrap CSS framework with Popper.js
• papaparse: CSV parsing library
• sortablejs: Drag-and-drop sorting
• swiperjs: Touch slider/carousel
• videojs: Video player
• howlerjs: Audio player

Example:

{
	"services": [
		{
			"name": "visualization-builder",
			"tracked_vars": [
				{ "currentVisualization": "object" },
				{ "availableTypes": "array" }
			],
			"actions": [
				"createVisualization",
				"updateVisualization",
				"deleteVisualization"
			],
			"helpers": ["validateConfig", "generatePreview"],
			"services": ["store", "router"]
		}
	]
}

Data Types Reference

Common Data Types

• string: Text values
• int: Integer numbers
• bool: Boolean true/false
• array: List of items
• object: Complex data structure
• var: Variable (any type)
• fn: Function reference

Argument Types

• var: Passed data/state
• fn: Callback function
• action: User interaction handler

Integration with Other Files

With simplified-types.json

• Model names used in routes should match type names from simplified-types.json
• Component inherited_args often reference model data pulled from store, and/or their fields
• Models are the gateway to persistent storage on the backend.

Best Practices

Always begin your thought process with routes → then move repeatable template route into components → then move your repeatable app-wide logic from components to services

1. Start with Routes: Match route names to user mental models and use consistent naming conventions
2. Minimize Route Logic: Preferably fetch (read) model data in routes and then pass that data to components or services. Other than fetching model data, minimize the use of javascript in routes - Javascript is meant to be in components and services more than in routes
3. Route Parameters: Keep get_vars minimal and meaningful, and load only necessary models for each route
4. Component Focus: Keep components focused on single responsibilities and use descriptive, kebab-case names
5. Data Flow: Receive backend data down from routes (via inherited_args) rather than fetching (reading) in components
6. Component Actions: Non-read functions - create, update, delete - can all happen well at component-level
7. Service Integration: Use services directly in components for app-wide logic
8. Service Architecture: Keep services stateless when possible and use dependency injection for service composition
9. Service Role: Services interact with both routes and components and store the core logic of the application

Tips for Manual Creation

1. Start with implementation_approach: Write a clear use case first
2. Identify key user journeys: Map these to routes
3. Break down UI into components: Focus on reusability
4. Define data flow: Ensure models align with your simplified-types.json
5. Plan service architecture: Keep core application logic separate from UI logic
6. Validate interconnections: Ensure all references match between files
7. Test component composition: Verify components work together logically
