Ben Guan, Vijay Shah, Jacob Stolker, Ryan Ziegler

Overview

ModelRocket was designed from the ground up to be horizontally scalable, and is divided into n core services:

1. Coordinator: responsible for autoscaling and processing updates to authentication. Written in Python, interfaces with Redis.
2. Model Manager: responsible for processing new model uploads and getting them ready for deployment. Written in NodeJS, interfaces with the Coordinator and Redis.
3. Inference Gateway: responsible for routing inference requests for a model to an appropriate upstream server. Written in Python, interfaces with Redis.
4. Inference Host: custom software running on servers to manage active models and provide fast inference. Written in Python, interfaces with Redis.
5. Python Client: allows the user to upload their model to our service with a single line of code. Detects model type and converts it to ONNX, then makes the necessary post requests to store the model in MongoDB and S3.
6. Web UI: allows users to manage their models and update API keys. Written in React.

Client Setup

• Pushing model to our service
  • usage: modelrocket.upload(model, model_name, input_type, input_shape)
    • This will output an api token and a model uuid.
• Making an inference request
  • usage: make a post request to the following link http://127.0.0.1:5000/inference with the following JSON body:

    {
        "token": api_token,
        "model": model_uuid,
        "inputs": {"modelInput": your_input_to_the_model}
    }


  • This will output a JSON object with the results of your inference.
• Website
  • Gives demonstration of how to write code for our service

Server Setup (required only if you want to host)

1. Install necessary packages for each service

   • Coordinator:
     • run cd coordinator
     • run pipenv install
     • run cd ..
   • Model Manager:
     • cd model-manager
     • Add a .env with the following variables:

         MONGODB_URL=
         ACCESS_KEY_ID=
         SECRET_ACCESS_ID=


     • run npm install
   • Inference Gateway:
     • run cd coordinator
     • run pipenv install
     • run cd ..
   • Inference Host:
     • run cd coordinator
     • run pipenv install
     • run cd ..

2. Run docker-compose up --detach

3. Run the following commands to set up environment variables:

   • AWS_ACCESS_KEY_ID=<your_access_key_id> AWS_SECRET_ACCESS_KEY=<your_secret_access_key></your_secret_access_key> S3_ENDPOINT=http://localhost:9000/ PORT=5002 python host.py
   • REDIS_HOST=localhost REDIS_PORT=6379 REDIS_PASSWORD=<your_password> REDIS_DB=0 python -m flask --app gateway run
   • REDIS_HOST=localhost REDIS_PORT=6379 REDIS_PASSWORD=<your_password> REDIS_DB=0 python assigner.py

4. S3 setup:

   • Go to localhost:9000
   • Sign in with your access key-id and secret-key.
   • Create a new bucket called models
