🌱 SPOTS: Sprouts Parallel Outcome Tree Search 🌱

Paper • Installation • Usage • Databases • BibTeX

SPOTS is a high-performance solver for the game of Sprouts, built on a massively parallel Proof-Number Search PNS-PDFPN. SPOTS is the first Proof-Number Search–based solver that scales efficiently to large CPU clusters. Applied to Sprouts, it achieves:

• ⚡ 332.9× speedup on 1024 CPU cores
• 📈 4 orders of magnitude faster runtime than the previous state-of-the-art solver GLOP
• 🤯 Proofs 1,000× more complex than previously reported
• 🏆 Verification of the Sprouts Conjecture for 42 new positions, nearly doubling known solved outcomes

---

✏️ Sprouts

Sprouts is a pencil-and-paper impartial game for two players introduced by John H. Conway and Michael Paterson in 1967. The game starts with n spots, and players then alternate by following these rules:

1. Draw a curve connecting two spots (or looping to one).
2. No crossings: curves may not touch or intersect any existing curve except at the endpoints.
3. Spot limit: each spot may have at most 3 incident edges (loops count twice).
4. Add a new spot somewhere along the drawn curve.
5. Normal play: the first player with no legal move loses.

🎯 Challenge

Solving Sprouts is a major computational benchmark:

• Designed Difficulty: It was intentionally created to be a simple-to-play but difficult-to-analyze.
• Extreme Complexity: Its game tree complexity grows exponentially, surpassing that of Chess and Go for even a small number of spots.
• Sprouts Conjecture: A long-standing conjecture motivates its study. It states the first player wins if and only if n mod 6 is 3, 4, or 5.

🧩 Project Overview

This project uses specialized algorithms to tackle Sprouts' complexity:

• Proof-Number Search (PNS): Sprouts features highly unbalanced game trees with a large branching factor. PNS is a best-first search algorithm that excels in these conditions, focusing on the most promising parts of the game tree.
• Grundy Numbers (GN, nimbers): As Sprouts is an impartial game, the Sprague-Grundy theorem can be applied. This allows the solver to reduce the complexity of game trees by analyzing independent subpositions separately, which often arise during a game.
• Massive Parallelization (PNS-PDFPN): The paper introduces PNS-PDFPN, a new algorithm that scales efficiently on many CPUs. It operates on two parallel levels:
  • First Level (Distributed): A master process assigns jobs to workers across different cluster nodes.
  • Second Level (Shared): Each worker node uses multiple threads (PDFPN) to parallelize its own search, utilizing shared memory.
  • Shared Results: Workers share key computed results (like Grundy numbers) to reduce search overhead and improve overall efficiency.

---

🛠️ Requirements

SPOTS requires the following system packages:

• python3-dev
• python3-venv
• build-essential (including GCC 11.4.0 or compatible)
• cmake (version ≥ 3.20)

To install these dependencies on Debian/Ubuntu systems:

sudo apt install python3-dev python3-venv build-essential cmake

---

📦 Installation

Clone the repository and install the project:

git clone https://github.com/cizektom/spots.git
cd spots

# Recommended: create a virtual environment
python3 -m venv .venv
source .venv/bin/activate

pip3 install .

This will automatically build:

• the C++ extension (spots_cpp) via CMake
• the Ray distributed framework

---

💻 Console Usage

Once installed, use:

spots-solver <position> --algorithm <algorithm> [options]

or:

python3 -m spots <position> --algorithm <algorithm> [options]

---

🚀 Quick Start

# Solve a 12-spot game using DFPN
spots-solver "0*12" --algorithm dfpn

# Use 4 threads (shared-memory parallel)
spots-solver "0*12" --algorithm pdfpn --threads 4

# Fully distributed solver (Ray)
spots-solver "0*12" --algorithm pns-pdfpn --workers 4

# Compute the nimber
spots-solver "0*10" --algorithm dfpn --compute_nimber

---

📋 Available Algorithms

Algorithm	Type	Description
dfs	Sequential	Depth-First Search
pns	Sequential	Proof-Number Search
dfpn	Sequential	Depth-First Proof-Number Search
pdfpn	Parallel	Shared-memory PDFPN (Kaneko, 2010)
pns-pdfpn	Distributed	Distributed PNS-PDFPN using Ray

---

🎛️ Command-Line Options

General

Option	Default	Description
--algorithm	required	dfs, pns, dfpn, pdfpn, pns-pdfpn
--compute_nimber	false	Compute Grundy number
--capacity	100_000	Transposition table size
--input_database	""	Input nimber DB
--output_database	database.spr	Output nimber DB
--stats_path	stats.csv	CSV statistics output
--verbose	false	Verbose mode
--seed	0	RNG seed

Parallel / Distributed

Option	Default	Description
--workers	1	Number of Ray workers
--threads	0	Threads per worker (0 = DFPN, >0 = PDFPN)
--iterations	100	Iterations per job
--updates	100	Worker update frequency
--grouping	1	Group size for nimber DB sharing
--no_sharing	false	Disable nimber sharing
--state_level	0	Retain: 0 = full, 1 = nimbers, 2 = none
--address	""	Connect to existing Ray cluster

---

🧪 Programmatic Usage

Sequential

from spots.solvers.sequential_solver import SequentialSolver

solver = SequentialSolver(game="Sprouts", algorithm="dfpn")
stats = solver.solve("0*12")
print(stats)

Shared-Memory Parallel

from spots.solvers.parallel_solver import ParallelSolver

solver = ParallelSolver(game="Sprouts", threads=4)
stats = solver.solve("0*12")
print(stats)

Distributed (Ray)

from spots.solvers.parallel_solver import DistributedSolver
import ray

ray.init()
solver = DistributedSolver(game="Sprouts", workers=4, threads=2)
stats = solver.solve("0*12")
print(stats)

---

🌐 Distributed Computing with Ray

Single Machine

ray start --head
spots-solver "0*12" --algorithm pns-pdfpn --workers 4 --threads 2

Multi-Node Cluster

On head node:

ray start --head

On each worker node:

ray start --address=<head_node_ip>

Run on head node:

spots-solver "0*12" --algorithm pns-pdfpn --workers 8 --address <head_node_ip>

More details: https://docs.ray.io/

---

📝 Position Format

Sprouts positions use the classical string encoding (Applegate, Jacobson, and Sleator, 1991; Lemoine and Viennot, 2015):

• "0*12" — 12-spot starting position
• "0*18|1a1a" — a 20-spot position with a connection between two spots

---

📊 Output and Statistics

SPOTS produces:

• Console output: live progress and final results
• CSV statistics: via --stats_path
• Nimber database: via --output_database

---

🗃️ Databases of Verified Results

SPOTS produces nimber databases that act as certificates of correctness for solved Sprouts positions. These databases allow the full reconstruction of reduced proof trees, following the verification method of Lemoine & Viennot (GLOP). All 32 outcomes computed by our sequential solver were fully verified using this procedure. The positions solved by the parallel solver are substantially larger and therefore could not be fully verified; nevertheless, by verifying several of its results on less complex positions, we confirmed that it produces correct solutions.

Below are the publicly available databases generated by SPOTS:

🔗 Download Databases

File	Size	Description
small_database.zip	136 MB	Nimber database certifying the 32 sequentially solved positions
large_database.zip	12 GB	Nimber database certifying the remaining 10 parallelly solved positions
small_verified_database.zip	9.5 MB	Verified nimber database certifying the 32 sequentially solved positions; contains only results required for proof reconstruction

These databases, together with the solver and verification procedure, make all reported results fully reproducible and externally verifiable.

---

📚 Citation

If you use SPOTS in your research, please cite:

@misc{cizek2025pns-pdfpn,
      title={Massively Parallel Proof-Number Search for Impartial Games and Beyond},
      author={Cizek, T. and Balko, M.  and Schmid, M.},
      year={2025},
      eprint={2511.10339},
      archivePrefix={arXiv},
}
