First prototype of an integrated Network Digital Twin (NDT) including the Edge

The technical features of the Demo deployment can be found in this repository. For this use case, the scenario is deployed on a container infrastructure using Kubernetes as the management tool.

To emulate the behavioral aspects of the transport and core network environment, KNE (Kubernetes Network Emulator by OpenConfig) has been used. Link-Layer Secure connectivity for Microservice platforms (L2S-M) is used to emulate the network edge.

Table of Contents

• Prerequisites:
  • KNE
  • L2S-M
• Overview of the Demo
• Demo
• NDT Deployment Guide

Prerequisites

KNE

Installation

• For installing KNE, follow the instructions provided in the official repository: KNE GitHub Repository.

Tested Environment

This demo was tested on a 4-node cluster with the following configuration:

• Kubernetes: v1.27.3
• Network Plugin: Flannel CNI
• Load Balancer: MetalLB
• Docker: Used as the CRI. Refer to the Docker installation guide. v20.10.21.
• Python: v3.8.10.
• Go: v1.20.1.
• Router Images: Arista cEOS-lab. Download the image from Arista's software download page.
  The image must be converted and imported as a Docker container image. Tested with the cEOS-lab-4.29.2F model.

L2S-M:

Installation

• For installing L2S-M, follow the instructions provided in the official repository: L2S-M GitHub Repository

Tested Environment

This demo was tested on a microK8s cluster with the following configuration:

• Kubernetes: MicroK8s v1.31.0 or later. Tested on a single-node cluster.
• Network Plugin: Multus CNI.

Overview of the Demo

The purpose of this demo is to showcase the first prototype of an edge-enabled Network Digital Twin, integrating two different twinning environments, KNE and L2S-M, which are open-source projects. The demo involves deploying a network with a web server on the network twin infrastructure and a client at the Edge, which will make web requests to the server. Additionally, a proxy will be deployed as an edge service handling requests from the client and forwarding them to the server. The main goal is to demonstrate that secure connections can be enabled for any kind of devices, providing the secure gatweay as close to the device as required.

1. Components of the NDT:

   • KNE: Used to emulate the Network.
   • L2S-M: Used to emulate the Edge.

2. Validation of the Demo The demo demonstrates an HTTP request sent from the client at the Edge to the web server in the network. The request passes through a reverse proxy at the Edge, which converts the HTTP request to HTTPS. Consequently, the web server uses only HTTPS, while the client at the Edge operates over HTTP, ensuring secure communication between the Edge and the network, restricting any interaction in the open to the local environment.

Demo

Demo Video

NDT Deployment Guide

TThe following steps provide a guide to deploy the NDT prototype (using a cluster with kubeadm), including the Edge (using a microk8s cluster). On the machine where KNE will be executed, you must ensure the cluster and KNE are up and running. Follow the instructions provided in the official repository KNE:

KNE

1. Install the necessary packages to use KNE

• Install go
• Install Docker
• Install kubectl

2. Deploy cluster configuration

kne deploy deploy/kne/enternal.yaml

3. Load images into a cluster

It is necessary to load the cEOS (Arista) image into the node worker of the cluster:

NOTE: ceos:latest is the default image to use for a node of vendor ARISTA. It's necessary to download the image from the official Arista website to access the cEOS image. In this demo, the tested version is 4.29.2F

cat cEOS-lab-4.29.2F.tar | docker import - ceos

L2S-M

On the machine where L2S-M will be executed, ensure that both the cluster and L2S-M are up and running. Follow the instructions provided in the official repository L2S-M.

Once the clusters with KNE and L2S-M are running, you can follow the steps below to create a connection between the two machines:

Connection Between Machines with KNE and L2S-M

Configuration on the Machine Hosting KNE Pods:

• Create a veth Pair

  Run the following commands to create a pair of virtual Ethernet interfaces:

  sudo ip link add veth2 type veth peer name veth3
  sudo ip link set veth2 up
  sudo ip link set veth3 up


Note: You must create the veth pair on the node that will host the pods of the topology.

• Create a VXLAN Interface

  Create a VXLAN interface with the following command, replacing with the IP address of the remote host:

  sudo ip link add vxlan-1 type vxlan id 96 dev enp1s0 dstport 47 remote  <remote-ip-host-L2S-M>
  sudo ip link set vxlan-1 up


• Create a Bridge and Add Interfaces:

  1. Install the bridge utilities package (if not already installed):

     sudo apt-get install bridge-utils


  2. Create a new bridge interface:

     sudo brctl addbr br0


  3. Add one end of the veth pair (veth2) and vxlan to the bridge:

     sudo brctl addif br0 veth2
     sudo brctl addif br0 vxlan-1


  Note:

  1. Only add one end of the veth pair because the other end (veth3) will be assigned to the gateway2 pod. For this demo, veth3 is already assigned in the Topology/Network/gateway2.yaml file.
  2. Has been tested on a cluster created with Kubeadm.

If you plan to deploy the network with KNE using a cluster such as Kind, follow this guide Kind

Configuration on the Edge Machine:

• Create a VXLAN Interface

  Create a VXLAN interface with the following command, replacing with the IP address of the remote host:

  sudo ip link add vxlan-1 type vxlan id 96 dev enp1s0 dstport 47 remote  <remote-ip-host-KNE>
  sudo ip link set vxlan-1 up


Once you have configured the connection between the machines, you can continue with the guide to proceed with the deployment of the NDT prototype:

Scenario Deployment on Machines with KNE and L2S-M

Deploy Network using KNE

To proceed with the next steps, you should have a functional Kubernetes cluster with KNE installed and operational for topology creation. For detailed installation instructions, please refer to the official guide in the repository KNE

1. Clone this repository from the cluster controller:

git clone <repository-url>

2. Install Ansible:

Using Ansible we have automated the deployment of the scenario. Therefore, You must have Ansible is already installed inside the machine where you want to deploy the topology If this is not the case:

sudo apt install ansible

3. To deploy of the topology execute the deployment.yaml file using the following command:

ansible-playbook ~/NDT-Prototype/Topology/deployment-kne/deployment.yaml

4. To configure the pods in the topology execute the config.yaml file using the following command:

ansible-playbook ~/NDT-Prototype/Topology/deployment-kne/config.yaml

4. To delete topology execute the undeploy.yaml file using the following command:

ansible-playbook ~/NDT-Prototype/Topology/deployment-kne/undeploy.yaml

Deploy Edge using L2S-M

Make sure your Kubernetes cluster is properly set up and that L2S-M is installed and operational. For comprehensive installation instructions, please refer to the official guide: L2S-M

1. Clone this repository from the cluster controller:

git clone <repository-url>

2. Install Ansible:

Using Ansible we have automated the deployment of the scenario. Therefore, You must have Ansible is already installed inside the machine where you want to deploy the topology If this is not the case:

sudo apt install ansible

3. To deploy of the pods execute the deployment.yaml file using the following command:

ansible-playbook ~/NDT-Prototype/Topology/deployment-l2s-m/deployment.yaml

4. To start the proxy and filter packets on the corresponding interfaces for ports 80 and 443, execute the config.yaml file using the following command:

ansible-playbook ~/NDT-Prototype/Topology/deployment-l2s-m/config.yaml

4. To delete pods execute the undeploy.yaml file using the following command:

ansible-playbook ~/NDT-Prototype/Topology/deployment-l2s-m/undeploy.yaml
